Description:
*V3-4M bytes (32Mbits) FLASH NodeMcu Lua WIFI
- WINDOWS driver USB to serial CH341 / CH340 installation package
- Support WINDOWS 98 / ME / 2000 / XP / Server 2003 / VISTA / Server 2008 / Win7 / Win8 / Win8.1 32 Bit / 64 and MAC
- Through Microsoft's digital signature authentication
- In the computer end of the USB device emulation as a standard serial devices Serial COM
- It contains the serial number and identification CH34X monitoring CH34X equipment swap library.
Specification :
- Processor: The NodeMCU V3 (CH340) is powered by the ESP8266 chip, which has a 32-bit Tensilica Xtensa LX106 RISC processor.
- Clock Frequency: The NodeMCU V3 (CH340) has a clock frequency of 80 MHz.
- Flash Memory: The NodeMCU V3 (CH340) has 4 MB of flash memory, which can be used to store the program and data.
- RAM: The NodeMCU V3 (CH340) has 80 KB of RAM, which can be used to store variables and data during runtime.
- Wi-Fi: The NodeMCU V3 (CH340) has built-in Wi-Fi connectivity with support for 802.11 b/g/n protocols.
- USB Interface: The NodeMCU V3 (CH340) has a micro USB interface that can be used to program and power the board.
- GPIO Pins: The NodeMCU V3 (CH340) has 17 GPIO pins, which can be used for input/output, PWM, I2C, and SPI communication.
- ADC: The NodeMCU V3 (CH340) has one analog-to-digital converter (ADC) input with a range of 0-3.3V and 10-bit resolution.
- Operating Voltage: The NodeMCU V3 (CH340) operates on a voltage range of 3.3V to 5V.
- Operating Current: The NodeMCU V3 (CH340) requires a maximum operating current of 200 mA.
- Programming Language: The NodeMCU V3 (CH340) can be programmed using the Arduino IDE with the ESP8266 core or Lua language.
- Dimensions: The NodeMCU V3 (CH340) has dimensions of 49mm x 24mm x 13mm.
